2.3.6 Pin Layout
The pin layout is also available at Bosch Motorsport website on MS 6 product page.
Most of MS 6 functions to pin relations may be modified to projects demands.
Please see details in the function description SWITCHMATRIX.
Bosch Motorsport tests check the defined connections of the pin layout.
Using a MS 6.1 or MS 6.3 version ensure not using analogue inputs of the measurement package without enabled license.
For MS 6.1 and MS 6.3 these hardware-options are only available if MS 6 measurement package is in use.
Analogue Inputs
ECU Pin
connector
>A<
ECU Pin
connector >K<
MS6.1 MS6.3
measure pack-
age
MS6.Cup
not available
I/O Type description pin related functions LEAD
AWG
MS6 default functionality function to pin coordination Measure
channel
A032 analog input pullup 3k01, 12bit 24 engine temperature PIN_IN_UTMOT utmot
A033 analog input pullup 3k01, 12bit 24 oil temperature PIN_IN_UTOIL utoil
A034 analog input pullup 3k01, 12bit 24 intake air temperature PIN_IN_UTINT utint
A035 Measure pack-
age
not available analog input pullup 3k01, 12bit 24 fuel temperature PIN_IN_UTFUEL utfuel
A079 analog input no pullup, 12bit angle- or time related
measurement
24 rail pressure PIN_IN_UPRAIL uprail
A080 Measure pack-
age
not available analog input no pullup, 12bit angle- or time related
measurement
24 rail pressure, bank 2 PIN_IN_UPRAIL2 uprail2
A081 analog input no pullup, 12bit 24 fuel pressure PIN_IN_UPFUEL upfuel
A082 analog input switch.-pullup 3k01 12bit CWPULLUP_A082 24 oil pressure PIN_IN_UPOIL upoil
A058 analog input no pullup, 12bit angle- or time related
measurement
24 pressure upstream throttle PIN_IN_UP21 up21
A059 Measure pack-
age
not available analog input switch.-pullup 1k47 for future dvlp., 12bit
angle- or time related measurement
24 pressure upstream throttle,
bank 2
PIN_IN_UP21_2 up21_2
A060 analog input no pullup, 12bit angle- or time related
measurement
24 intake manifold pressure, mean
value
PIN_IN_UP22M up22m
A061 Measure pack-
age
not available analog input switch.-pullup 1k47 for future dvlp., 12bit
angle- or time related measurement
24 intake manifold pressure, mean
value, bank 2
PIN_IN_UP22M_2 up22m_2
A056 analog input no pullup, 12bit 24 APS potentiometer a fixed function to pin coordina-
tion
uaps_a
A054 analog input no pullup, 12bit 24 APS potentiometer b fixed function to pin coordina-
tion
uaps_b
A041 analog input no pullup, 12bit 24 throttle potentiometer fixed function to pin coordina-
tion
uthrottle
A053 analog input no pullup, 12bit 24 backup throttle potentiometer fixed function to pin coordina-
tion
uthrottle_b
A036 not available analog input no pullup, 12bit 24 throttle potentiometer, bank 2 fixed function to pin coordina-
tion
uthrottle2
A037 not available analog input no pullup, 12bit 24 backup throttle potentiometer,
bank 2
fixed function to pin coordina-
tion
uthrottle2_b
