Bosch MS 6 - Analog Input Pin Assignments (Continued)

2 | Technical Data
14/76 Engine_Control_Unit_MS_6.x_Manual Bosch Motorsport
K036 analog input pullup 3k01, 12bit 24 map switch PIN_IN_UMAPSW umapsw
K031 analog input switch.-pullup 3k01 12bit CWPULLUP_K031 24 pitspeed switch PIN_IN_UPITSPEEDSW upitspeedsw
K019 Measure pack-
age
analog input switch.-pullup 3k01 12bit CWPULLUP_K019 24 launch control switch PIN_IN_ULAUNCHSW ulaunchsw
K015 analog input switch.-pullup 3k01 12bit CWPULLUP_K015 24 traction control switch PIN_IN_UTCSW utcsw
K016 Measure pack-
age
not available analog input switch.-pullup 3k01 12bit CWPULLUP_K016 24 reset chassis channels switch PIN_IN_UCHRESSW uchressw
K017 Measure pack-
age
not available analog input switch.-pullup 3k01 12bit CWPULLUP_K017 24 wet track switch PIN_IN_UWETSW uwetsw
A039 analog input no pullup, 12bit 24 gear position PIN_IN_UGEARP ugearp
A055 Measure pack-
age
analog input switch.-pullup 3k01 12bit CWPULLUP_A055 24 reverse shift switch PIN_IN_UREVSW ushiftrevsw
A057 Measure pack-
age
analog input switch.-pullup 3k01 12bit CWPULLUP_A057 24 downshift switch PIN_IN_USHIFTDNSW ushiftdnsw
A076 Measure pack-
age
analog input switch.-pullup 3k01 12bit CWPULLUP_A076 24 upshift switch PIN_IN_USHIFTUPSW ushiftupsw
A077 analog input switch.-pullup 3k01 12bit CWPULLUP_A077 24 gearshift PIN_IN_UGS ugs
A078 Measure pack-
age
analog input switch.-pullup 3k01 12bit CWPULLUP_A078 24 free measure channel A78
A038 Measure pack-
age
analog input no pullup, 12bit 24 gearbox pneumatic pressure PIN_IN_UPGEARAIR upgearair
K033 Measure pack-
age
analog input no pullup, 12bit 24 clutch pressure PIN_IN_UPCLUTCH upclutch
K048 Measure pack-
age
not available analog input no pullup, 12bit 24 free measure channel K48
K047 digital input fixed pullup to 5volts 24 laptrigger fixed function to pin coordina-
tion
lapctr
A040 analog input no pullup, 12bit 24 brake pressure rear PIN_IN_UPBRAKE_R upbrake_r
K020 analog input switch.-pullup 3k01 12bit CWPULLUP_K020 24 brake pressure front PIN_IN_UPBRAKE_F upbrake_f
K018 Measure pack-
age
not available analog input switch.-pullup 3k01 12bit CWPULLUP_K018 24 damper sensor front/left PIN_IN_UDAM_FL udam_fl
K032 Measure pack-
age
not available analog input no pullup, 12bit 24 damper sensor front right PIN_IN_UDAM_FR udam_fr
K034 Measure pack-
age
not available analog input no pullup, 12bit 24 damper sensor rear left PIN_IN_UDAM_RL udam_rl
K035 Measure pack-
age
not available analog input no pullup, 12bit 24 damper sensor rear right PIN_IN_UDAM_RR udam_rr
K050 Measure pack-
age
not available analog input no pullup, 12bit 24 steering angle PIN_IN_USTEER usteer
K077 Thermo-
couple input
k-type sensor 24shield
thermo
exhaust gas temperature fixed function to pin coordina-
tion
utexh
K076
K079 Measure pack-
age
not available Thermo-
couple input
k-type sensor 24shield
thermo
exhaust gas temperature bank 2 fixed function to pin coordina-
tion
utexh2
K078 Measure pack-
age
not available
