Bosch MS 6 - Digital Input Pin Assignments

Technical Data | 2
Bosch Motorsport Engine_Control_Unit_MS_6.x_Manual 15/76
Digital Inputs
ECU Pin con-
nector >A<
ECU Pin con-
nector >K<
MS6.1 MS6.3
measure pack-
age
MS6.Cup
not avail-
able
I/O Type description pin related functions LEAD
AWG
MS6 default functionality function to pin coordination Measure
channel
A047 crankshaft+
(Hall/Induct-
ive)
switchable between halleffect- and in-
ductive sensor
CWINTF_CRANK
PIN_IN_CRANK
CWINTF_CRANK_K
CWINTF_CRANK_TH
24shield engine speed fixed function to pin coordin-
ation
nmot
A048 crankshaft -
(inductive)
24shield
A074 digital input halleffect sensor only 24shield camshaft inlet PIN_IN_CAM_IN cam_pos_edg
es_001
A075 digital input halleffect sensor only 24shield camshaft outlet PIN_IN_CAM_OUT cam_pos_edg
es_out_001
A049 digital input switchable between halleffect- or DF11
sensors
CWINTF_A049 24shield camshaft inlet bank2 or
wheelspeed front right
PIN_IN_CAM_IN2 or
PIN_IN_FWEEL_FR
cam_pos_edg
es2_001 or
fwheel_fr
A050 digital input switchable between halleffect- or DF11
sensors
CWINTF_A050 24shield camshaft outlet bank2 or
wheelspeed front left
PIN_IN_CAM_OUT2 or
PIN_IN_FWEEL_FL
cam_pos_edg
es_out2_001
or fwheel_fl
A051 digital input switchable between halleffect- or DF11
sensors
CWINTF_A051 24shield wheelspeed rear right PIN_IN_FWHEEL_RR fwheel_rr
A052 digital input switchable between halleffect- or DF11
sensors
CWINTF_A052 24shield wheel speed rear left PIN_IN_FWHEEL_RL fwheel_rl
K045 digital input switchable between halleffect- and in-
ductive sensor
CWINTF_K045
CWINTF_K045_K
CWINTF_K045_TH
24shield turbo speed PIN_IN_FTURBO fturbo
K046 digital input switchable between halleffect- and in-
ductive sensor
CWINTF_K046
CWINTF_K046_K
CWINTF_K046_TH
24shield turbo speed bank2 PIN_IN_FTURBO2 fturbo2
K062 ground sup-
ply
if inductive sensos are connected to K045
or K046
24shield ground for turbo speed and--2
K054 digital input B_engon 20 Engine On/Off switch b_engon(_in)
A013 knock input 24shield knock sensor 1, bank1 KCSENCYL ikcraw_n_..
A014 knock input 24shield knock sensor 2, bank1 KCSENCYL ikcraw_n_..
A015 not avl. knock input 24shield knock sensor 1, bank2 KCSENCYL ikcraw_n_..
A016 not avl. knock input 24shield knock sensor 2, bank2 KCSENCYL ikcraw_n_..
A017 knock sensor
ground
24shield
K085 Lambda_IA LSU4.9 probe only 24 Lambda fixed function to pin
coordination
lambda
K086 Lambda_IP 24
K087 Lambda_UN 24
K088 Lambda_VM 24
K068 not avl. Lambda_IA LSU4.9 probe only 24 Lambda bank2 fixed function to pin
coordination
lambda2
K069 not avl. Lambda_IP 24
