Bosch MS 6 - Ignition and Injection Output Pin Assignments

2 | Technical Data
16/76 Engine_Control_Unit_MS_6.x_Manual Bosch Motorsport
K070 not avl. Lambda_UN 24
K071 not avl. Lambda_VM 24
Ignition- & Injection Outputs
ECU Pin
connector >A<
ECU Pin
connector >K<
MS6.1 MS6.3
measure pack-
age
MS6.Cup
not avail-
able
I/O Type description pin related
functions
LEAD
AWG
MS6 default functionality function to pin coordination Measure
channel
A026 ignition driver output related to mechanical cylinder
number;
use of coil integrated power stages only
CWIGNDRV_MODE
IGNDRV_CURRENT
24 Ignition cyl.1 CYLNUMBER
CYLANGLE
ign_out_n_00
1
A027 24 Ignition cyl.2 ign_out_n_00
2
A028 24 Ignition cyl.3 ign_out_n_00
3
A029 24 Ignition cyl.4 ign_out_n_00
4
A030 not avl. 24 Ignition cyl.5 ign_out_n_00
5
A031 not avl. 24 Ignition cyl.6 ign_out_n_00
6
A068 not avl. 24 Ignition cyl.7 ign_out_n_00
7
A069 not avl. 24 Ignition cyl.8 ign_out_n_00
8
A070 not avl. 24 ignition cyl.9 ign_out_n_00
9
A071 not avl. 24 ignition cyl.10 ign_out_n_01
0
A072 not avl. 24 ignition cyl.11 ign_out_n_01
1
A073 not avl. 24 ignition cyl.12 ign_out_n_01
2
A098 low pressure
output for
high imp.
injectors
output related to mechanical cylinder
number
24twist Injection cyl.1 CYLNUMBER
CYLANGLE
or
(PIN_OUT_LPINJ_A098
…
PIN_OUT_LPINJ_A084)
tinj_n_001
A100 24twist Injection cyl.2 tinj_n_002
A101 24twist Injection cyl.3 tinj_n_003
A096 24twist Injection cyl.4 tinj_n_004
A099 not avl. 24twist Injection cyl.5 tinj_n_005
A103 not avl. 24twist Injection cyl.6 tinj_n_006
A042 not avl. 24twist Injection cyl.7 tinj_n_007
A105 not avl. 24twist Injection cyl.8 tinj_n_008
A018 not avl. 24twist Injection cyl.9 tinj_n_009
A020 not avl. 24twist Injection cyl.10 tinj_n_010
A063 not avl. 24twist Injection cyl.11 tinj_n_011
A084 not avl. 24twist Injection cyl.12 tinj_n_012
