Technical Data | 2
Bosch Motorsport Engine_Control_Unit_MS_6.x_Manual 19/76
Network
ECU Pin
connector >A<
ECU Pin
connector
>K<
MS6.1 MS6.3
measure package
MS6.Cup
not avail-
able
I/O Type description pin related
functions
LEAD
AWG
MS6 default functionality function to pin coordination Measure
channel
K029 CAN Bus1 high uptp 1Mbit/s switchable 120Ohm ter-
minator
CWCAN1_TERM CAN CAN1 E_can1
K012 CAN Bus1 low
K028 CAN Bus2 high uptp 1Mbit/s switchable 120Ohm ter-
minator
CWCAN2_TERM CAN CAN2 E_can1
K011 CAN Bus2 low
K027 CAN Bus3 high uptp 1Mbit/s switchable 120Ohm ter-
minator
CWCAN3_TERM CAN CAN3 E_can1
K010 CAN Bus3 low
K052 Serial interface RS232_RX 24twist telemetry use
K053 RS232_TX
K044 Ethernet 1 ETH1RX+ CAT7 Communication PC to device
K043 ETH1RX-
K042 ETH1TX+
K041 ETH1TX-
K061 Ethernet 2 ETH2RX+ CAT7 extended communication to
PBx90, DDU7, DDU8 or C60
K060 ETH2RX-
K059 ETH2TX+
K058 ETH2TX-
K025 not avl. USB USB_DP USB use for additional data stick
K024 not avl. USB_DN
K007 not avl. USB_GND
K008 not avl. USB_VBUS
K014 TIMESYNC timeline 24 data synchronising for Ether-
net extension modules
K066 not in use
K067 not in use
K083 not in use
K084 not in use
K051 LIN-Bus CWLINMODE 24 LIN communication
K030 TN digital output TNSIG_PULSENUM
TNSIG_PWM
24 rpm-signal PIN_OUT_K030
K013 TN digital output 24 flywheel-signal PIN_OUT_K013
K037 TN digital output 24 triggerwheel-signal PIN_OUT_K037
