Bosch MS 6 - Power Supply Pin Assignments

2 | Technical Data
20/76 Engine_Control_Unit_MS_6.x_Manual Bosch Motorsport
Power Supplies
ECU Pin
connector
>A<
ECU Pin con-
nector >K<
MS6.1 MS6.3
measure package
MS6.Cup
not avail-
able
I/O Type description pin related functions LEAD
AWG
MS6 default functionality function to pin coordination Measure
channel
K003 battery plus UDYNPOWER 14 dynamic power supply
K005 battery plus UDYNPOWER 14 dynamic power supply
K006 battery plus UDYNPOWER 14 dynamic power supply
K075 battery plus UBAT 20 digital power supply
K001 battery minus 14
K002 battery minus 14
K004 battery minus 14
A009 sensor supply
5V/50mamp
recommended supply for: aps_a, etc 24 ETC sensor supply 1
A011 sensor supply
5V/50mamp
recommended supply for: aps_b, etc2 24 ETC sensor supply 2
K065 sensor supply
5V/150mamp
CW5VOUT3_EN 24 5 V sensor supply 4
A007 sensor supply
5V/50mamp
24 5 V sensor supply 5
A005 sensor supply
5V/150mamp
CW5VOUT1_EN 24 5 V sensor supply 1
K064 sensor supply
5V/150mamp
CW5VOUT2_EN 24 5 V sensor supply 2
K063 sensor supply
5V/50mamp
24 5 V sensor supply 3
K080 sensor ground 1 20 ground sensor supply
K081 sensor ground 2 20 ground sensor supply
K082 sensor ground 3 20 ground sensor supply
A006 sensor ground 4 20 ground sensor supply
A008 sensor ground 5 20 ground sensor supply
A010 sensor ground 6 recommended ground for: aps_a, etc 20 ground sensor supply
A012 sensor ground 7 recommended ground for: aps_b,
etc2
20 ground sensor supply
A062 shield ground 24 sensor shields
K021 shield ground 24 sensor shields
K026 shield ground 24 Ethernet and LIN shields
K049 not used
K009 shield ground 24 USB shield
A083 not in use
