Pack201 | Operator Interface | Section 4
EN | 46
© Bosch Packaging Technology, Inc.
All rights reserved 2012
PARAMETER DEFINITION
Cutting Head Circumference (mm) This is the measured distance around the dwell head cam track�
(300mm) Dwell head machine only�
Cutting Head Diameter (mm) This is the measured distance between the center of the upper and
lower cutting head shafts� Rotary head machine only�
Cycle Stop Position (deg) This is the position of the endseal crimpers when the wrapper comes to
a cycle stop�
Delay NGNS This is the number of cycles (packages) between the No Gap No Seal
eye and the wrapper endseal crimpers�
Discharge Reject Enable In the ON position the discharge reject system is active� In the OFF posi-
tion the reject is disabled�
Discharge Speed Ratio This is the ratio of the cutting head speed to the discharge conveyor
speed� Used to increase or decrease gaps between packages�
Dwell Width This is a value that can be added to match the crimper width to the lm
speed�
Feeder Enable In the ON position the feeder is active� In the OFF position the feeder is
disabled�
Feeder Speed Range (ppm) The wrapper goes to set speed minus this value when the feeder speed
eye is unblocked�
Film Max Correction (mm) This is the maximum amount of more or less length the wrapper can
correct when the sealing material is out of registration�
Film Max Error Reg This is the maximum amount that a registered package can be out of
registration without being rejected�
Film Run Rate This is the desired lm speed in packages per minute when the machine
is in lm jog mode.
Film Stop Value This value (a percentage of the package length) is used to stop the lm
when the No Product No Paper eye is activated�
Flush/Evacuation Start Speed This is the speed the wrapper must reach before the air evacuation or
gas ush turn on.
Flush/Evacuation Stop Speed This is the speed the wrapper must reach before the air evacuation or
gas ush turns off.
Gas Flush Enable In the ON position the gas ush option is active. In the OFF position the
option is disabled�
Generic 1 (or 2) # To Reject (prod) This is the desired number of packages to reject when the reject condi-
tion is detected�
Generic 1 (or 2) Reject Enable In the ON position the generic reject is active� In the OFF position the
reject is disabled�
Generic 1 (or 2) Reject Shifts (prod) This is the number of cycles from the generic reject eye to the reject
device�
High Product # To Reject This is the number of products to reject when a high product is detect-
ed�
High Product Reject (on/off) In the ON position the high product reject eye is active� In the OFF posi-
tion the reject eye is disabled�
High Product Reject Shifts This is the number of cycles from the high product reject eye to the
reject device�
