Message Action
SHORT PRODUCT REJECT� SHORT PRODUCT DETECTED AND REJECTED�
HIGH PRODUCT REJECT� HIGH PRODUCT DETECTED AND REJECTED�
LOW PRESSURE FEEDER INCREASING� CHECK THE FEEDBACK PUSH THE ESTOP BUTTON TO RESET THE
FOLLOWING ERROR OR PRESS START BUTTON TO RUN�
LOW PRESSURE FEEDER DECREASING� THE LPF IS DECREASING TO THE NEW OFFSET�
SIDE CHAIN INCREASING� THE SIDE CHAIN IS INCREASING TO THE NEW OFFSET�
SIDE CHAIN DECREASING� THE SIDE CHAIN IS DECREASING TO THE NEW OFFSET�
LINESHAFT X INCREASING� THE LINESHAFT IS INCREASING TO THE NEW OFFSET�
REJECT VERIFICATION ERROR� A PRODUCT THAT WAS TO BE REJECTED WAS DETECTED BY THE
VERIFY EYE� REMOVE THE PRODUCT� PRESS START BUTTON TO
RUN�
GENERIC REJECT GENERIC REJECT DETECTED AND THE PRESET AMOUNT OF
PRODUCT HAS BEEN REJECTED�
SYNC REJECT� MACHINE LOST SYNCHRONIZATION AND THE PRESET AMOUNT OF
PRODUCT HAS BEEN REJECTED�
VISION REJECT VISION REJECT DETECTED AND THE PRESET AMOUNT OF PROD-
UCTS TO REJECT HAVE BEEN REJECTED�
VISION DATA NOT VALID STOP� MACHINE CYCLE STOPPED BY DATA VALID SIGNAL NOT TRANSI-
TIONING� CHECK THE WIRING AND VISION SYSTEM FOR ERRORS�
VISION SYSTEM CONSECUTIVE STOP� THE MACHINE HAS CYCLE STOPPED BECAUSE MORE REJECTS
HAVE CONSECUTIVELY OCCURED THAN THE PRESET AMOUNT AL-
LOWS�
SHORT PRODUCT CONSECUTIVE STOP� CHECK THE PRODUCT FOR SHORT/MISSING� CHECK THE PROD-
UCT FLOW FOR ERRORS�
VISION SYSTEM NOT READY� MACHINE CYCLE STOPPED BY VISION SYSTEM THE VISION SYS-
TEM FOR ERRORS�
FINWHEEL/PFR SWITCH OPEN� CLOSE THE SWITCH(ES) AND PRESS START TO RUN�
MISSED REGISTRATION MARK CONSECUTIVE
STOP�
CHECK THE FILM TRACKING AND THE REGISTRATION EYE�
POWER FEED ROLL IS TOO TIGHT� CHECK FOR THE POWER FEED ROLLERS TO BE OPEN
NO PRODUCT / NO PAPER EYE ERROR� CHECK THE PRODUCT FLOW AND THE EYE SETUP�
MFG SPLICE EYE ERROR� CHECK THE TWO EYES IN THE CIRCUIT AND MAKE SURE
BOTH ARE SEEING AT THE SAME TIME�
VERIFICATION EYE ERROR� CHECK TO SEE THAT GOOD PRODUCT IS PASSING IN FRONT OF
VERIFICATION EYE� THEN CHECK SETUP OF EYE�
BAD CONFIGURATION FILE� THE MACHINE CONFIGURATION FILE HAS BECOME CORRUPTED
OPTIONAL GUARD OPEN� CLOSE THE GUARD TO RUN THE MACHINE�
EPROM WRITE FAILURE� NOTIFY THE FACTORY�
OVERHEAD SWEEP FOLLOWING ERROR� CHECK THE FEEDBACK PUSH THE ESTOP BUTTON TO RESET
FOLLOWING ERROR OR PRESS START BUTTON TO RUN�
