BoschRexrothAG, RE91405-01-B/2021-05-21
20/52 A2FO series 70 | Transport and storage
6 Transport and storage
▶ Always observe the required ambient conditions for transport and storage;
seechapter 6.2 "Storing the axial piston unit" on page 22.
Information on unpacking can be found in chapter7.1 "Unpacking" on page24.
6�1 Transporting the axial piston unit
The following transportation options are available depending on weight and duration
of transport:
• Transport by hand
• Transporting with alifting device (eye bolt or lifting strap)
Table 6: Dimensions and weights
Size 45 56 63 80 90 107 125
Ground kg 17 17 17 23 23 32.8 32.8
Width mm
Dimensions vary by equipment. The values applicable for your axial piston unit
can be found in the installation drawing (request if necessary).
Height mm
Depth mm
Weight may vary by equipment.
6�1�1 Transport by hand
Up to aspecific maximum weight, axial piston units can be transported by hand for
ashort distance. Observe the national regulations in your country. To prevent health
damage, we recommend renouncing any transport by hand.
CAUTION! Risk of injury due to heavy loads!
Health hazard from carrying axial piston units.
▶ Only manually transport the axial piston unit for ashort period of time.
Observe the national regulations in your country for manual transport.
▶ Always use appropriate lifting, lowering and moving techniques.
▶ Use your personal protective equipment (e.g.safety goggles, safety gloves,
suitableworking clothes, safety shoes).
▶ Do not transport the axial piston unit by sensitive assembled parts
(e.g.sensors or valves).
▶ Carefully place the axial piston unit on the seating to prevent it from being
damaged.
Dimensions and
weights
