Bosch rexroth A2FO Series User Manual

RE91405-01-B/2021-05-21, BoschRexrothAG
About this documentation | A2FO series 70 7/52
1�3�2 Symbols
The following symbols indicate notices that are not safety-relevant but increase
understanding of the documentation.
Table 3: Meaning of symbols
Symbol Meaning
If this information is disregarded, the product cannot be used and/or
operated to its full extent.
▶
Single, independent action
1�
2�
3�
Numbered instruction:
The numbers indicate that the actions must be completed in order.
1�3�3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
A2FO Axial piston fixed pump, open circuit
Threaded plug Metal screw, pressure-resistant
Protective plug Made out of plastic, not pressure-resistant, only for transportation
As ageneric term for the "axial piston fixed pump A2FO series 70", the designation
"axial piston unit" will be used in the following.
1�3�4 Abbreviations
This documentation uses the following abbreviations:
Table 5: Abbreviations
Abbreviation Meaning
ANSI American National Standards Institute is an organization that coordinates
the development of voluntary standards in the United States
ATEX EC directive on explosion protection (Atmosphère explosible)
DIN Deutsches Institut für Normung (German Institute for Standardization)
ISO International Organization for Standardization
JIS Japan Industrial Standard
RE Rexroth document in the English language
VDI2230 Guideline for the systematic calculation of heavy-duty
threaded connections and cylindrical screw joints from the VDI
(VereinDeutscherIngenieure - Association of German Engineers)
