Bosch rexroth A2FO Series User Manual

RE91405-01-B/2021-05-21, BoschRexrothAG
About this documentation | A2FO series 70 5/52
1 About this documentation
1�1 Validity of the documentation
This documentation is valid for the following products:
• Axial piston fixed pump A2FO series 70
This documentation is intended for machine/system manufacturers, assemblers and
service engineers.
This documentation contains important information on the safe and proper
transport, assembly, commissioning, operation, maintenance, removal and simple
troubleshooting of the axial piston unit.
▶ Read this documentation completely, in particular chapter 2 "Safety instructions"
on page 8 and chapter 3 "General instructions on property damage and
product damage" on page 14 before you start work with the axial piston unit.
1�2 Required and supplementary documentation
▶ Only commission the axial piston unit if the documentation marked with the book
symbol
is available to you and you have understood and observed it.
Table 1: Required and supplementary documentation
Title Document number Document type
Order confirmation
Contains the order-related technical data of your axial piston fixed
pumpA2FOseries 70.
– Order confirmation
Installation drawing
Contains the outer dimensions, all connections and the hydraulic circuit diagram
for your axial piston fixed pump A2FOseries 70.
Please request the
installation drawing
from your contact at
BoschRexroth.
Installation drawing
Axial piston fixed pump A2FO series 70
Contains the permissible technical data, ports, main dimensions and circuit
diagrams of standard versions.
91405 Datasheet
Hydraulic fluids based on mineral oils and related hydrocarbons
Describes the requirements on a hydraulic fluid on mineral oil basis and related
hydrocarbons for operation with Rexroth hydraulic components and assists you in
selecting a hydraulic fluid for your hydraulic system.
90220 Datasheet
Environmentally acceptablehydraulic fluids
Describes the requirements on an environmentally acceptablehydraulic fluid
for operation with Rexroth hydraulic components and assists you in selecting
ahydraulic fluid for your hydraulic system.
90221 Datasheet
BoschRexroth Fluid Rating List for Rexroth hydraulic components
(pumps and motors)
Contains the hydraulic fluids positively evaluated by BoschRexroth.
90245 Datasheet
Information on the application of hydrostatic drives at low temperatures
Contains additional information on the application of Rexroth axial piston units
at low temperatures.
90300-03-B Datasheet
Storage and preservation of axial piston units
Contains additional information on storage and preservation.
90312 Datasheet
