5.2 SD card
Ordering code Part number Description
XACC-0-SD016GB R911404022 Micro SD card, 16 GB
5.3 RJ45 cable
Ordering code Part number Description
RKB0020 R911340676 Bus cable
5.4 End clamp
Ordering code Part number Description
SUP-M01-ENDHALTER R911170685 2 pieces of snap-on end brackets for 35 mm NS
35/7.5 support rail; width: 9.5 mm
5.5
Endcover
Ordering code Part number Description
XACC-2-ENDCOVR R911412178
5.6
Wear parts
The physical read-only memory (eMMC) of the control has a limited number of write cycles. Retrieve the
current status of the read-only memory via the ctrlX CORE web interface:
“ctrlX CORE side navigation
🠂
Settings
🠂
Information
🠂
tab "Resources"
🠂
Sensors”
.
Notes on sensor values:
• "0 - 10% of eMMC life time used" means that up to 10 % of the maximum write cycles can be used.
• Create a backup if the value exceeds 80%.
•
Replace the hardware if the value exceeds 80%.
•
Use an external memory to extend the service life of the permanent memory.
• The frequency of the refresh cycle depends on the service life of the memory. If a refresh cycle is
not possible anymore, data can be lost.
Notes on the temperature display:
•
"Temperature (CPU)" shows the internal CPU temperature.
• "Temperature" shows the temperature on the PCB.
Spare parts, accessories and wear parts
