The IndraControl extension modules can be used for complex connections to
controls that cannot be operated at the S20 bus, such as interface modules to
Profinet, Profibus, CAN and Sercos or Safety connection.
The IndraControl extension modules may only be operated under the mounting
and installation conditions, the position and the ambient conditions (tempera-
ture, degree of protection, humidity, EMC etc.) specified in this documentation.
5
Spare parts, accessories and wear parts
5.1 Connector 24 V
Ordering code Part number Description
XA-CN01 R911173741 24 V plug
Tab. 5-1: Connector, 24 V
5.2 Connector set for the CAN module
Ordering code Part number Description
S20-CNS 2S-O/D/UI/E1/E2 R911173804 Connector set for the 24 V module and the
CAN module
Tab. 5-2: Connector set CAN module
5.3 Bus base module
Ordering code Part number Description
XA-BS11 R911173772 Bus base module for extension modules
Tab. 5-3: Bus base module for extension bus
5.4 End clamp
Ordering code Part number Description
SUP-M01-ENDHALTER R911170685 2 pieces of snap-on end brackets for 35
mm NS 35/7.5 or NS 35/15 carrier plate;
width: 9.5 mm
Tab. 5-4: End clamp
5.5 Wear parts
There are no wear parts in the extension modules.
Bosch Rexroth AG
Spare parts, accessories and wear parts
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
6/37
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
