RT Ethernet extension module
24 V supply with FE to XF40 845 V AC, 50 Hz, 1 min
24 V supply with FE to XF41 845 V AC, 50 Hz, 1 min
XF40 to XF41 845 V AC, 50 Hz, 1 min
Sercos extension module
24 V supply with FE to XF3 845 V AC, 50 Hz, 1 min
24 V supply with FE to XF4 845 V AC, 50 Hz, 1 min
XF3 to XF4 845 V AC, 50 Hz, 1 min
CAN extension module
24 V supply to XF70 845 V AC, 50 Hz, 1 min
24 V supply to XF71 845 V AC, 50 Hz, 1 min
24 V supply to FE 845 V AC, 50 Hz, 1 min
XF70 to FE 845 V AC, 50 Hz, 1 min
XF71 to FE 845 V AC, 50 Hz, 1 min
XF70 to XF71 845 V AC, 50 Hz, 1 min
Tab. 7-2: Operating voltage and current consumption
Electronic damage due to polarity reversal or
due to a nominal current that is too low
The power supply unit has to be able to deliver the quadruple nominal current of
the protective fuse to ensure that the fuse reliably triggers in case of an error.
8
Standards
The products have been developed according to the German edition of the
standards published at the time of product engineering.
8.1
Standards used
Standard Meaning Edition
IEC 60204-1 Electrical equipment of machines 2007
IEC 61131-2 Programmable controllers 2008
IEC 60529 Degrees of protection provided by enclosures (IP Code) 2014
IEC 61010-2-201 Safety requirements for electrical equipment for measure-
ment, control and laboratory use
2014
UL 61010-2-201 Safety requirements for electrical equipment for measure-
ment, control and laboratory use
2014
Tab. 8-1: Standards used
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
Bosch Rexroth AG
Standards
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
9/37
