Bosch Rexroth IndraControl XFE 01.1 Series User Manual

15 Ordering information
15.1 Type code
Type short description
1
2
3
4
5
6
7
8
9
1
0
1
2
3
4
5
Example:
X F E 0 1 . 1 - F B - 1 0
01
Device type 1
I/O
box................... = X
02
Device type 2
Function extension
... = F
03
Extension type
Ext. board (detachable) = B
Ext. card (plug-in)
........ = C
Ext. module (modular) .
= E
04
Type of construction
Type 1
- PCIe ................. = 01
Type 2
– S20 .................. = 02
05
Design
HW
design .................................
= 1
06
Function type
Communication interface
..................
= CX
Field bus
........................................... = FB
I/O connection
.................................. = IO
Safety
............................................... = SY
1)
Memory, volatile
................................ = M0
07
Function (corresponding to the function
t
ype)
Field bus
No field bus
................................................ = 00
Sercos master
.............................................. = 01
Sercos slave
................................................ = 02
RT
-Ethernet configurable master ................. = 03
RT
-Ethernet configurable slave ................... = 04
Profibus master
...................................... = 10
Profibus slave
........................................ = 11
CAN Master (netX)
...................................... = 12
CAN Slave (netX)
........................................ = 13
CAN master 2 x (passive)
............................. = 20
CAN slave 2 x (passive)
............................... = 21
CAN master 4 x (passive)
............................. = 22
CAN slave 4 x (passive)
............................... = 23
Safety
Safe Logic to SIL3
....................................... = 01
1)
Note:
1)
Function type “SY” only available with function Safety “01”
Fig. 15-1: Type code
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
Bosch Rexroth AG
Ordering information
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
29/37
