8.4 Explosion protection certification (XFE01.1-FB-03, XFE01.1-
FB-20)
II 3G
Ex ec IIC Gc
TÜV 16 ATEX 7949 U
IECEx TUR 16.0049 U
Ex Explosion protection label
II Equipment group II: Explosive gas
atmospheres
3G Equipment category 3: Explosive at-
mosphere (zone 2)
Ex Explosion protection label
ec Type of protection "Increased safety"
IIC Gas group IIC, hydrogen
Gc Equipment protection level (EPL),
rare and momentary explosive at-
mosphere (zone 2): Flammable
gases, vapors, mists
TÜV... ATEX EU type examination certificate
IECEx... IECEx certificate number
...U Component marking
Fig. 8-1: Exemplary type plate
The approval numbers given on the type plate are marked at the end with an "X"
for devices and a "U" for components. "X" indicates special conditions to be ob-
served together with the safety and health regulations given in the standards.
"U" indicates a component (Ex component) that may not be used on its own.
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
Bosch Rexroth AG
Standards
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
11/37
