6 Ambient conditions
In operation
Ambient temperature in oper-
ation
Up to 2,000 m:
-25 °C to +60 °C
2,000 m to 3,000 m:
-25 °C to +55 °C
Ambient temperature during
storage and transport
–40 °C to +85 °C
Permitted air humidity 5 % to 95 % acc. to DIN EN 61131-2
Condensation not allowed
Operating altitude Up to 3,000 m above sea level acc. to DIN 61010-1
Mechanical strength
①
Vibration stress:
● Oscillations, sinusoidal in all three axes acc. to DIN EN 60068-2-6
5-9 Hz with an amplitude of 3.5 mm
9-150 Hz with 5 g peak acceleration
● Broadband noise acc. to DIN EN 60068-2-64
5-20-150 Hz with 0.572 g, 5 h per axis
Shock stress: Shock resistance in all three axes acc. to DIN EN
60068-2-27
11 ms semi-sinusoidal 30 g
Overvoltage category 2
Contamination level 2
Degree of protection IP20 acc. to DIN EN 60 529
Protection class III, DIN EN 61010-2-201
① The vibration stress specifications assume the use of industrial-suited RJ45 plug connec-
tions. The "Industrial RJ45 plug" of the company Yamaichi is recommended (Y-Con-
Plug-41). The cables are available as accessories (RKB0020). To protect against vibration,
secure the cables with a short distance (< 20 cm).
Tab. 6-1: Ambient conditions
Failure of the product due to contaminated air
● The ambient air must not contain acids, alkaline solutions, corrosive agents,
salts, metal vapors and other electrically conductive contaminants in high
concentrations
● Housing and installation compartments must at least comply with the degree
of protection IP 54 according to DIN EN 60529
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
Bosch Rexroth AG
Ambient conditions
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
7/37
