2 Product identification and scope of delivery
2.1 Product identification and type plate
U
0.6 A
Made in Germany
IndraControl S20
SN: 7260007123456BC
FD: 12W16
7260
FW: 101
N
N
I-V-C-B-T-V
Functional
Safety
Type
Approved
FI: 001
CERTIFIED
www.tuv.com
ID 10000000000
MNR: R911172531 -AA0
Bosch Rexroth AG, Bgm.-Dr.-Nebel-Str. 2
DE-97816 Lohr Hotline: +49 9352 405060
DC 24 V
I
Ex ec IIC Gc
IECEx TUR 16.0049 U
TÜV 16 ATEX 7949 U
II 3G
"IND.CONT.EQ"
32FB
16 channels
Wire Range 24-16
2700729
1 2 3 4 5 6 7 8 9
101112
13
14
15
16
17
1819
1 Word mark
2 Part number
3 Device name
4 State of revision
5 Functional index
6 Plant number
7 Serial number
8 Serial number as barcode
9 Date of manufacture (yyWww)
10 CE conformity marking
11 Company address
12 Underwriters Laboratories Inc. mark
13 Check digit
14 Nominal current
15 Nominal voltage
16 Manufacturing country
17 Software release
18 QR code
19 Explosion protection marking
Fig. 2-1: Exemplary type plate
2.2
Scope of delivery
● Extension module
● Bus base
● 24 V power connector XA-CN01
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
Bosch Rexroth AG
Product identification and scope of delivery
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
3/37
