Keep the “Fallback” pushbutton of the respective module pressed using a
plastic pen until the display LED "ON" at the extension module is on. This
loads a backup data set. Release the “Fallback” pushbutton.
Perform this step for all extension modules, whose display LED "ON" was
not on. After completing that for all extension modules, the display LED
"ON" of the XMxx control is on.
The "XMxx" control can only start if all connected extension modules
started without any errors. If the LED "ON" is not on at a connected
extension module with “Fallback” mode, actively initiate the “Fall-
back” mode.
14 Maintenance
14.1 General information
Maintenance work in the device is only permis-
sible by skilled staff!
If hardware or software components have to be exchanged, please contact the
Bosch Rexroth Service or ensure that only skilled staff changes the respective
components.
14.2 Regular maintenance tasks
Include the following measures into the maintenance schedule:
● Check all plug and terminal connections of the components for proper tight-
ness and possible damage at least once a year
● Make sure that cables are not broken or crimped
● Replace damaged parts immediately
Bosch Rexroth AG
Maintenance
Extension Modules Profibus, RT-
Ethernet, Sercos, CAN
28/37
DOK-CONTRL-XFE**EXTMOD-IT04-EN-P
