Bosch RF Series - Corner Weights (Horizontal Cabinets Only)

Specification Tables
20.4 Corner Weights (Horizontal Cabinets Only)
Table 21 Corner Weights (HZ)
Model
Left-Hand Evaporator Right-Hand Evaporator
Total
Left Front*
Right
Front*
Left Back Right Back Left Front*
Right
Front*
Left Back Right Back
RF007 HZ
lbs. 144.0 39.6 35.4 32.2 36.8 35.4 39.6 36.8 32.2
kg. 65.3 18.0 16.1 14.6 16.7 16.1 18.0 16.7 14.6
RF009 HZ
lbs. 136.6 42.4 33.4 28.2 32.6 33.4 42.4 32.6 28.2
kg. 62.0 19.2 15.1 12.8 14.8 15.1 19.2 14.8 12.8
RF012 HZ
lbs. 153.0 42.4 38.4 33.8 38.4 38.4 42.4 38.4 33.8
kg. 69.4 19.2 17.4 15.3 17.4 17.4 19.2 17.4 15.3
RF015 HZ
lbs. 155.0 44.6 38.2 33.8 38.4 38.2 44.6 38.4 33.8
kg. 70.3 20.2 17.3 15.3 17.4 17.3 20.2 17.4 15.3
RF018 HZ
lbs. 173.0 51.8 41.0 37.2 43.0 41.0 51.8 43.0 37.2
kg. 78.5 23.5 18.6 16.9 19.5 18.6 23.5 19.5 16.9
RF024 HZ
lbs. 193.8 47.2 62.2 47.2 37.2 62.2 47.2 37.2 47.2
kg. 87.9 21.4 28.2 21.4 16.9 28.2 21.4 16.9 21.4
RF030 HZ
lbs. 204.2 50.4 61.6 54.0 38.2 61.6 50.4 38.2 54.0
kg. 92.6 22.9 27.9 24.5 17.3 27.9 22.9 17.3 24.5
RF036 HZ
lbs. 205.2 61.6 46.6 40.6 56.4 46.6 61.6 56.4 40.6
kg. 93.1 27.9 21.1 18.4 25.6 21.1 27.9 25.6 18.4
RF042 HZ
lbs. 281.0 70.4 88.0 78.0 44.6 88.0 70.4 44.6 78.0
kg. 127.5 31.9 39.9 35.4 20.2 39.9 31.9 20.2 35.4
RF048 HZ
lbs. 292.0 77.0 89.8 75.6 49.6 89.8 77.0 49.6 75.6
kg. 132.4 34.9 40.7 34.3 22.5 40.7 34.9 22.5 34.3
RF060 HZ
lbs. 324.2 96.7 91.9 71.1 64.7 91.9 96.7 64.7 71.1
kg. 147.1 43.8 41.7 32.2 29.3 41.7 43.8 29.3 32.2
RF070 HZ
lbs. 320.6 108.4 87.2 51.4 73.6 87.2 108.4 73.6 51.4
kg. 145.4 49.2 39.6 23.3 33.4 39.6 49.2 33.4 23.3
*The front is the control box end of the unit.
