Dimensional Drawings
22 Dimensional Drawings
22.1 Vertical (VT) Unit Dimensions
Table 23 Vertical (VT) Unit Dimensions
Model RF007 RF009 RF012 RF015 RF018 RF024 RF030 RF036 RF042 RF048 RF060 RF070
Condensate Drain
Connection
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT
Recommended
Replacement Nominal
Filter Size
17" x 19" 17" x 19" 17" x 19" 17" x 19" 18" x 22" 18" x 22" 19" x 27" 24" x 30" 24" x 30" 24" x 30"
18" x 30"
(2 Filters)
18" x 30"
(2 Filters)
Condenser Water
Connections
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 1" FPT 1" FPT 1" FPT
A
Width
21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 24" 24" 24" 24"
B
Depth
21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 26" 26" 26" 33" 33"
C
Height
33" 33" 33" 33" 39" 39" 39" 44" 44" 44" 51" 51"
D
Discharge Depth
4" 4" 4" 9.5" 9.5" 9.5" 10.5" 10.5" 10.5" 10.5" 12.5" 12.5"
E
Discharge Width
6.75" 6.75" 6.75" 9.25" 9.25" 9.25" 9.75" 9.75" 10.5" 10.5" 11.75" 11.75"
F
Cabinet Edge to
Discharge
7.25" 7.25" 7.25" 4.25" 4.25" 4.25" 2.25" 5.75" 5" 5" 9" 9"
G
Cabinet Edge to
Discharge
(Left-Hand
Return)
7.5" 7.5" 7.5" 6.25" 6.25" 6.25" 6.25" 5.5" 6.75" 6.75" 6.25" 6.25"
H
Water Inlet
3.5" 3.5" 3.5" 3" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25" 3" 3"
J
Water Outlet
8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.25" 8.25"
K
Condensate
Drain
5.75" 5.75" 5.75" 5.75" 6" 6.25" 5.84" 5.75" 5.75" 5.75" 5.75" 5.5"
M
R/A Duct Width
17.5" 17.5" 17.5" 17.5" 18" 18" 16.25" 24" 23.75" 23.75" 27.25" 27.25"
N
R/A Duct Flange
Height
15" 15" 15" 15" 20" 20" 24.75" 28" 28" 28" 34" 34"
P
Filter Rack
Height
17.25" 17.25" 17.25" 17.25" 22.25" 22.25" 22.25" 30" 31.25" 31.25" 37.25" 37.25"
Q
Cabinet Edge to
Discharge
(Right-Hand
Return)
7.5” 7.5” 7.5” 6.25" 6.25" 6.25" 6.25" 5.58" 6.75" 6.75" 6.25" 6.25"
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Overall u
nit dimensions do not include filter rack or duct
flanges.
