Bosch RF Series - Horizontal (HZ) Cabinet Options Dimensions

Dimensional Drawings
22.4 Horizontal (HZ) Cabinet Options Dimensions
Table 26 Horizontal (HZ) Cabinet Options Dimensions
Model RF007 RF009 RF012 RF015 RF018 RF024 RF030 RF036 RF042 RF048 RF060 RF070
Filter Rack Options
AA
2" Filter Rack
2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25”
BB
Filter Rack
Height
0.92” 0.92” 0.92” 0.92” 0.78” 0.78” 1” 1” 0.75” 0.75” 0.75” 0.75”
CC
R/A Duct Flange
Height
14” 14” 14” 14” 15.25” 15.25” 16” 16” 18” 18” 18” 18”
DD
R/A Duct Flange
Width
22” 22” 22” 22” 23” 23” 28” 28” 32” 32” 42” 46”
HRP
EE
HRP Inlet
N/A N/A N/A N/A N/A 4.75” 4.75” 4.75” 4.75” 4.75” 4.5” 4.5”
FF
HRP Outlet
N/A N/A N/A N/A N/A 7” 7” 7” 7” 7” 7” 7”
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Filter ra
ck dimensions does not include 1" duct flange.
• 2" filter racks can accept either a 1" or 2" filter.
• HRP Connections are 1/2" FNPT.
76 |
RF Series Heat Pumps — 8733980022 (2024/12)
