Bosch RF Series - Wiring Diagrams; Single-Stage, Single-Phase, Standard Unit with Constant Torque (CT) Motor

Wiring Diagrams
21 Wiring Diagrams
21.1 Single-Stage, Single-Phase, Standard Unit with Constant Torque (CT) Motor
Fig. 28 Single-Stage, Single-Phase, Standard Unit with CT Motor
FOR REFERENCE ONLY Actual unit wiring may vary from this
example. Always refer to the wiring diagram attached to the unit.
68 |
RF Series Heat Pumps — 8733980022 (2024/12)
