Bosch VPV 16 - Page 90

VPV Vane Pump 89
2000 PSI Cutaway – VPV 45 – 164
25
Torque to 350 lb/in
(Torque to 39.5 Nm)
TYPE “P1” VANE PUMP
COMBO CAPABLE
22
4
3
2
8
9
10
15
14
16
17
6
18
1
21
20
19
VPV 45/63/80
Torque to 1800 lb/in
(Torque to 204 Nm)
Torque to 850 lb/in
(Torque to 96 Nm)
Torque to 850 lb/in
(Torque to 96 Nm)
Torque to 12 lb/in
(Torque to 1.4 Nm)
7
24
23
5
13
VPV 100/130/164
Torque to 4970 lb/in
(Torque to 562 Nm)
