INSTALLATION
63
|
ENG
Details on making the connections
The pinouts for the optional installed connector are detailed in the table below.
PIN NUMBER COLOR PURPOSE
1 Red
V+IN: Headset power (10-32 VDC). Use a 1/4 amp
fuse or a 1/2 amp circuit breaker.
2 Black
GND: System ground. Connect to the existing
audio ground.
3 White COMM L: Phone communication, Left.
4 Blue COMM R: Phone communication, Right.
NOTE: For stereo operation, connect the left and right channels to their respective positions.
For monaural operation, connect pins 3 and 4 together, and to the tip of the existing
phone jack.
5 White
MIC HI: Microphone/Hi-audio. Connect to the
portion of the existing microphone jack that
corresponds to the ring position of a headset
microphone plug. Don’t connect to the tip
(PTT) segment.
6 White/Blue
MIC LO: Microphone/Lo-ground. Connect to the
portion of the microphone jack that corresponds to
the barrel position of a headset microphone plug.
NOTE: If the microphone works on radio transmit but not through the intercom, check pin 6.
It may be incorrectly wired to the PTT segment of the microphone jack.
Comm Shield Black Shield from Comm L and Comm R wire pair.
Mic Shield Black Shield from Mic Hi and Mic Lo wire pair.
NOTE: The wires connecting pins 3 and 4 and pins 5 and 6 are shielded, twisted pairs with a
black wire shield termination exiting each pair. If the existing wiring is not shielded,
connect the shields to the existing audio wiring shields, or connect the shield from
Comm L and Comm R wire pair to audio ground.
