SPECIFICATIONS
Power Output (all channels loaded): Bass Channel: 140 Watts at 100 Hz into 4 Ohms
Satellite Channels: 35 Watts at 1 kHz into 8 Ohms
Distortion: Bass Channel: < 0.4% THD at 0.5W
Satellite Channels: < 0.1% THD at 0.5W
Output Noise: Bass Channel: < 2 mVrms, unweighted
Satellite Channels: < 400 uVrms, A weighted
Signal to Noise Ratio: 96 dB
DC Offset: < 50 mVdc, all channels
Satellite Balance:
+ 1.5 dB for volume settings 0 to -79 dB
Satellite Separation: > 40 dB at 1 kHz, > 30 dB at 10 kHz, stereo mode
Standby Line Power: < 5 W at rated line voltage (plugged in, music center off)
Idle Line Power: < 15 W at rated line voltage (plugged in, music center
on and muted)
Analog Input Impedance: 5.0k Ohms + 10% at 1 kHz
S/PDIF Input Impedance: 75 Ohms + 10% at 100 kHz
Analog Input Sensitivity: 0.5 Vrms input at 100 Hz/1 kHz for rated power in
bass/satellite channels
Analog Input CMRR: > 40 dB at 60 Hz, within + 12V common mode
Compressor: > 20 dB compression from 200-10 kHz with distortion
throughout the compression range < 3% at 1 kHz and
< 4% at 50 Hz
Turn On Delay: 1.5 Seconds maximum
Turn Off Delay: < 200 mS
Volume Control Attenuation Range: 0 dB to -80 dB
Center Volume Control Range: -6 dB to 0 dB in 1 dB steps, 0 dB to 9 dB in 1.5 dB steps
Surround Volume Control Range: -6 dB to 0 dB in 1 dB steps, 0 dB to 9 dB in 1.5 dB steps
Audio Inputs: Audio and audio for video
Control Inputs: IR, Serial (RS-232), Speaker Data (Music Center), and
TV Sense (logic level)
Indicators: Power, Standby/Command, Setup/Analog Input, Fault/
Digital Input
Power Supply: 110-120 Vac, 60 Hz, 400W, 3.63 Amps
Dimensions: 15.75"H x 10.75"W x 3.38"D (40cm x 27.3cm x 8.6cm)
Unit Weight: 16 lbs (7.25 kg)
