Bose BUILT-INvisible TA-1 User Manual

65
1
2
3
8
7
9
CTL
4
6
5
Bubble Wrap (vendor supplied)
Product Carton
(vendor supplied)
SE-1 AUDIO/VIDEO SWITCHER
Figure 5. SE-1 Audio/Video Switcher Packing Diagram
Item
Number
Description Part Number Qty.
1 POWER PACK, 12 VDC, 500 mA VENDOR SUPPLIED 1
2 CABLE ASSY, IR SENSOR 260074-1 1
3 CABLE ASSY, SOURCE, 7 FT. 257180 1
4 CABLE ASSY, 3.5mm TO 8 PIN MINI DIN, 6 FT. 261489 1
5 CABLE ASSY, S-VIDEO, 6 FT. VENDOR SUPPLIED 1
6 CABLE ASSY, COMPOSITE VIDEO, 6 FT. VENDOR SUPPLIED 1
7 CABLE ASSY, DIG AUDIO, RCA TO RCA, 6 FT. VENDOR SUPPLIED 1
8 SE-1 AUDIO/VIDEO SWITCHER, GRAY 260047 1
9 SE-1 INSTALLATION GUIDE 262007 1
