Bose BUILT-INvisible TA-1 User Manual

35
I/O PCB ELECTRICAL PART LIST
Resistors
Reference
Designator
Description Part Number Note
RN1 5K, RESNET, SOIC 16, 1/10W, 1% 250124-5001
RN2 5K, RESNET, SOIC 16, 1/10W, 1% 250124-5001
RN3 5K, RESNET, SOIC 16, 1/10W, 1% 250124-5001
RN4 5K, RESNET, SOIC 16, 1/10W, 1% 250124-5001
R1 4.99K, 0805, 1/10W, 1% 133625-4991
R2 2K, 0805, 1/10W, 1% 133625-2001
R3 470 OHM, 0805, 1/10W, 1% 133625-4700
R4 470 OHM, 0805, 1/10W, 1% 133625-4700
R8 4.99K, 0805, 1/10W, 1% 133625-4991
R9 100K, SM, 0805, 1/10W, 1% 133625-1003
R10 100 OHM, 0805, 1/10W, 1% 133625-1000
R11 47K, 0805, 1/10W, 1% 133625-4702
R12 47K, 0805, 1/10W, 1% 133625-4702
R13 47K, 0805, 1/10W, 1% 133625-4702
R14 10K, 0805, 1/10W, 1% 133625-1002
R15 20K, 0805, 1/10W, 1% 133625-2002
R16 20K, 0805, 1/10W, 1% 133625-2002
R17 2K, 0805, 1/10W, 1% 133625-2001
R18 2K, 0805, 1/10W, 1% 133625-2001
R19 2K, 0805, 1/10W, 1% 133625-2001
R20 4.99K, 0805, 1/10W, 1% 133625-4991
R21 2K, 0805, 1/10W, 1% 133625-2001
R22 2K, 0805, 1/10W, 1% 133625-2001
R23 2K, 0805, 1/10W, 1% 133625-2001
R24 2K, 0805, 1/10W, 1% 133625-2001
R25 75 OHM, 0805, 1/10W, 1% 133625-75R0
R26 2K, 0805, 1/10W, 1% 133625-2001
R27 2K, 0805, 1/10W, 1% 133625-2001
R28 75 OHM, 0805, 1/10W, 1% 133625-75R0
R29 4.75K, 0805, 1/10W, 1% 133625-4751
R30 4.75K, 0805, 1/10W, 1% 133625-4751
R31 4.75K, 0805, 1/10W, 1% 133625-4751
R32 4.75K, 0805, 1/10W, 1% 133625-4751
R33 4.75K, 0805, 1/10W, 1% 133625-4751
R34 4.75K, 0805, 1/10W, 1% 133625-4751
R35 4.75K, 0805, 1/10W, 1% 133625-4751
R36 4.75K, 0805, 1/10W, 1% 133625-4751
R37 75 OHM, 0805, 1/10W, 1% 133625-75R0
R38 4.99K, 0805, 1/10W, 1% 133625-4991
R39 75 OHM, 0805, 1/10W, 1% 133625-75R0
R40 10K, 0805, 1/10W, 1% 133625-1002
R44 200K, 0805, 1/10W, 1% 133625-2003
R45 200K, 0805, 1/10W, 1% 133625-2003
R46 200K, 0805, 1/10W, 1% 133625-2003
R47 200K, 0805, 1/10W, 1% 133625-2003
R48 200K, 0805, 1/10W, 1% 133625-2003
