Bose BUILT-INvisible TA-1 User Manual

36
Resistors (continued)
I/O PCB ELECTRICAL PART LIST
Reference
Designator
Description Part Number Note
R49 10 OHM, 0805, 1/10W, 1% 133625-10R0
R53 10 OHM, 0805, 1/10W, 1% 133625-10R0
R63 10 OHM, 0805, 1/10W, 1% 133625-10R0
R64 10 OHM, 0805, 1/10W, 1% 133625-10R0
R65 10 OHM, 0805, 1/10W, 1% 133625-10R0
R66 100 OHM, 0805, 1/10W, 1% 133625-1000
R67 10K, 0805, 1/10W, 1% 133625-1002
R69 200 OHM, 0805, 1/10W, 1% 133625-2000
R70 10 OHM, 0805, 1/10W, 1% 133625-10R0
R71 330 OHM, 0805, 1/10W, 1% 133625-3300
R72 1K, 0805, 1/10W, 1% 133625-1001
R73 10 OHM, 0805, 1/10W, 1% 133625-10R0
R74 10K, 0805, 1/10W, 1% 133625-1002
R75 2K, 0805, 1/10W, 1% 133625-2001
R76 300 OHM, 0805, 1/10W, 1% 133625-3000
R77 47K, 0805, 1/10W, 1% 133625-4702
R78 75 OHM, 0805, 1/10W, 1% 133625-75R0
R79 47K, 0805, 1/10W, 1% 133625-4702
R80 2K, 0805, 1/10W, 1% 133625-2001
R81 0 OHM, 0805, 1/10W 133627
R82 100 OHM, 0805, 1/10W, 1% 133625-1000
R83 10K, 0805, 1/10W, 1% 133625-1002
R84 10K, 0805, 1/10W, 1% 133625-1002
R86 100 OHM, 1206, 1/8W, 1% 124894-1000
R87 0 OHM, 0805, 1/10W 133627
R88 300 OHM, 0805, 1/10W, 1% 133625-3000
R89 10K, 0805, 1/10W, 1% 133625-1002
R90 100 OHM, 0805, 1/10W, 1% 133625-1000
R91 0 OHM, 0805, 1/10W 133627
R92 10K, 0805, 1/10W, 1% 133625-1002
R93 10K, 0805, 1/10W, 1% 133625-1002
R94 0 OHM, 0805, 1/10W 133627
R95 10K, 0805, 1/10W, 1% 133625-1002
R98 2K, 0805, 1/10W, 1% 133625-2001
R99 100K, SM, 0805, 1/10W, 1% 133625-1003
R104 4.99K, 0805, 1/10W, 1% 133625-4991
R105 1.0K, 1206, 1/8W, 1% 124894-1001
R106 1.0K, 1206, 1/8W, 1% 124894-1001
R108 470 OHM, 0805, 1/10W, 1% 133625-4700
R109 1.0K, 1206, 1/8W, 1% 124894-1001
R112 1.0K, 1206, 1/8W, 1% 124894-1001
R115 100K, SM, 0805, 1/10W, 1% 133625-1003
R116 1.0K, 1206, 1/8W, 1% 124894-1001
R117 1.0K, 1206, 1/8W, 1% 124894-1001
R118 1.0K, 1206, 1/8W, 1% 124894-1001
R119 1K, 0805, 1/10W, 1% 133625-1001
