AMPLIFIER PCB ELECTRICAL PART LIST
Resistors
Reference
Designator
Description Part Number Note
R700 22.1K, 1206, 1/8W, 1% 124984-2212
R701 274K, 1206, 1/8W, 1% 124894-2743
R702 1.50K, 1206, 1/8W, 5% 124895-1525
R703 1.50K, 1206, 1/8W, 5% 124895-1525
R704 5.1 OHM, FUSING, 2W, 5% 170174-5R1 3
R705 1.50K, 1206, 1/8W, 5% 124895-1525
R706 1.50K, 1206, 1/8W, 5% 124895-1525
R707 75 OHM, 1206, 1/8W, 5% 124895-7505
R708 22.1K, 0805, 1/10W, 1% 133625-2212
R709 10.0K, 0805, 1/10W, 1% 133625-1002
R710 5.1 OHM, 1206, 1/8W, 5% 124895-5R15
R711 220 OHM, 1206, 1/8W, 5% 124895-2215
R712 75 OHM, 1206, 1/8W, 5% 124895-7505
R713 20 OHM, FUSING, 1/4W, 5% 130102-200 3
R714 20 OHM, FUSING, 1/4W, 5% 130102-200 3
R715 100K, 1206, 1/8W, 5% 124895-1045
R716 274K, 1206, 1/8W, 1% 124894-2743
R717 100K, 1206, 1/8W, 5% 124895-1045
R718 274K, 1206, 1/8W, 1% 124894-2743
R719 2.49K, 1206, 1/8W, 1% 124894-2491
R720 49.9K, 1206, 1/8W, 1% 124894-4992
R721 49.9K, 1206, 1/8W, 1% 124894-4992
R722 2.49K, 1206, 1/8W, 1% 124894-2491
R723 16.5K, 1206, 1/8W, 1% 124894-1652
R724 1.0K, 1206, 1/8W, 5% 124895-1025
R725 100K, 1206, 1/8W, 5% 124895-1045
R726 1.0K, 1206, 1/8W, 5% 124895-1025
R727 100K, 1206, 1/8W, 5% 124895-1045
R728 100K, 1206, 1/8W, 5% 124895-1045
R729 2.49K, 1206, 1/8W, 1% 124894-2491
R730 1.0K, 1206, 1/8W, 5% 124895-1025
R731 3.65K, 1206, 1/8W, 1% 124894-3651
R732 1.0K, 1206, 1/8W, 5% 124895-1025
R733 100K, 1206, 1/8W, 5% 124895-1045
R734 3.65K, 1206, 1/8W, 1% 124894-3651
R735 1.0K, 1206, 1/8W, 5% 124895-1025
R736 49.9K, 1206, 1/8W, 1% 124894-4992
R737 16.5K, 1206, 1/8W, 1% 124894-1652
R738 49.9K, 1206, 1/8W, 1% 124894-4992
R739 2.49K, 1206, 1/8W, 1% 124894-2491
R740 10.0K, 1206, 1/8W, 5% 124895-1035
R741 1.0K, 1206, 1/8W, 5% 124895-1025
R742 100K, 1206, 1/8W, 5% 124895-1045
