Bose BUILT-INvisible TA-1

64
Item Number Description Part Number Note
1
Conn, Binding Post, Model 203

, Gray
187232-003
2 Screw, Tapp, 8-11 x .75, PAN, XRC/SQ 172672-12
3 Insert, Packing 259825
4 Bag, Poly, 23 x 44 x 10.5 x 1.25 mil 100652
5 Packing, Corner Post 130759
6 Packing, Crease Sheet 196633
7
Packing, End Cap, AM-5

P
139955
8 Bracket, Mounting, Series II Bass Module 259830
9 Bag, Poly, 14.38 x 9.87 x 2 mil 103351
10 Hardware Kit, Installation, Bass Module 259831
11 Card, Registration and Warranty 262933
12 Sheet, Installer’s Guide, Bass Module 259824
13 Carton, Series II Bass Module 259826-001
BUILT-INVISIBLE
®
SERIES II BASS MODULE
Note: The BUILT-INvisible Series II Bass Module is non-repairable.
12
11
9
13
10
5
(2)
6
(2)
7
8
4
3
1
(4)
2
