37
Capacitors
I/O PCB ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part Number Note
R120 1.0K, 1206, 1/8W, 1% 124894-1001
R121 100K, SM, 0805, 1/10W, 1% 133625-1003
R122 100K, SM, 0805, 1/10W, 1% 133625-1003
R123 1K, 0805, 1/10W, 1% 133625-1001
R124 100K, SM, 0805, 1/10W, 1% 133625-1003
R125 100K, SM, 0805, 1/10W, 1% 133625-1003
R126 1.0K, 1206, 1/8W, 1% 124894-1001
R127 1.0K, 1206, 1/8W, 1% 124894-1001
R128 200K, 0805, 1/10W, 1% 133625-2003
R129 470 OHM, 0805, 1/10W, 1% 133625-4700
R130 100 OHM, 0805, 1/10W, 1% 133625-1000
R131 1.0K, 1206, 1/8W, 1% 124894-1001
Reference
Designator
Description Part Number Note
C1 47pF, 0805, C0G, 50V, 5% 133622-470
C2 1000pF, 0805, X7R, 50V, 10% 133623-102
C3 270pF, 0805, C0G, 50V, 5% 133622-271
C4 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C5 270pF, 0805, C0G, 50V, 5% 133622-271
C6 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C7 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C8 47pF, 0805, C0G, 50V, 5% 133622-470
C10 270pF, 0805, C0G, 50V, 5% 133622-271
C11 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C12 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C13 1000pF, 0805, X7R, 50V, 10% 133623-102
C14 270pF, 0805, C0G, 50V, 5% 133622-271
C15 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C16 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C17 15pF, 0805, C0G, 50V, 5% 133622-150
C18 15pF, 0805, C0G, 50V, 5% 133622-150
C19 47pF, 0805, C0G, 50V, 5% 133622-470
C20 1000pF, 0805, X7R, 50V, 10% 133623-102
C21 270pF, 0805, C0G, 50V, 5% 133622-271
C22 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C23 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C24 1000pF, 0805, X7R, 50V, 10% 133623-102
C25 270pF, 0805, C0G, 50V, 5% 133622-271
C26 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C27 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C28 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C29 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C30 47pF, 0805, C0G, 50V, 5% 133622-470
