Capacitors (continued)
I/O PCB ELECTRICAL PART LIST
Reference
Designator
Description Part Number Note
C31 1000pF, 0805, X7R, 50V, 10% 133623-102
C32 270pF, 0805, C0G, 50V, 5% 133622-271
C33 .033uF, 0805, X7R, 50V, 5% 133623-3335
C34 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C35 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C37 270pF, 0805, C0G, 50V, 5% 133622-271
C38 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C39 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C40 .033uF, 0805, X7R, 50V, 5% 133623-3335
C41 .033uF, 0805, X7R, 50V, 5% 133623-3335
C42 .033uF, 0805, X7R, 50V, 5% 133623-3335
C44 .033uF, 0805, X7R, 50V, 5% 133623-3335
C45 .033uF, 0805, X7R, 50V, 5% 133623-3335
C46 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C47 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C48 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C49 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C50 22uF, ALUM EL, SM, 16V, 85C, 20% 177902-220C
C51 1000uF, EL, 105C, 35V, 20% 261416-102
C52 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C53 4.7uF, AL EL, SM, 35V, 85C, 20% 177902-4R7V
C54 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C55 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C56 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C57 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C58 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C59 22uF, ALUM EL, SM, 16V, 85C, 20% 177902-220C
C60 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C61 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C62 47pF, 0805, C0G, 50V, 5% 133622-470
C64 47pF, 0805, C0G, 50V, 5% 133622-470
C67 1000pF, 0805, X7R, 50V, 10% 133623-102
C68 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C69 .068uF, 0805, X7R, 50V, 10% 133622-683
C70 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C71 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C72 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C73 .068uF, 0805, X7R, 50V, 10% 133622-683
C74 1000pF, 0805, X7R, 50V, 10% 133623-102
C75 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C76 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C77 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C78 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C79 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C80 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
C81 .1uF, SM, 0805, X7R, 50V, 10% 133623-104
