Bose BUILT-INvisible TA-1 User Manual

39
Reference
Designator
Description Part Number Note
Q1 NPN, SOT23, 2SC2812 134741
Q2 NPN, SOT23, 2SC2812 134741
Q4 NPN, SOT23, 2SC2812 134741
Q5 RELAY, SSR, LO-RON, 6-PIN, SMT 252450 3
Q6 TRIAC, 8A, 600V, D2PAK 197226 3
Q7 NPN, SOT23, 2SC2812 134741
I/O PCB ELECTRICAL PART LIST
Diodes
Transistors
Reference
Designator
Description Part Number Note
D1 ZENER, SOT23, 7.5V 261419
D2 DUAL, BAV99R-R, SOT23 147239
D3 LED, TH, 3MM, IR, 1.2V 256474
D8 DUAL, BAV99R-R, SOT23 147239
D9 DUAL, BAV99R-R, SOT23 147239
D18 DUAL, BAV99R-R, SOT23 147239
D19 DUAL, BAV99R-R, SOT23 147239
D21 DUAL, BAV99R-R, SOT23 147239
D22 RECTIFIER, BRIDGE, 50V, 1.0A 112027
D23 DUAL, BAV99R-R, SOT23 147239
D24 DUAL, BAV99R-R, SOT23 147239
D25 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D26 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D27 LED, TH, 5MM, 2V, DIFFUSE, GRN 261420-05
D28 LED, TH, 5MM, 2V, DIFFUSE, YEL 261420-07
D29 LED, TH, 5MM, 2V, DIFFUSE, RED 261420-01
D30 LED, TH, 5MM, 2V, DIFFUSE, YEL 261420-07
D31 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D32 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D33 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D34 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D35 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D36 DUAL, BAV99R-R, SOT23 147239
D37 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D38 DUAL, BAV99R-R, SOT23 147239
D39 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D40 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
D41 DUAL, ZENER, SOT23, 16V, COMMON ANODE 261414
