Bose BUILT-INvisible TA-1 User Manual

40
I/O PCB ELECTRICAL PART LIST
Integrated Circuits
Miscellaneous
Reference
Designator
Description Part Number Note
U1 OP AMP, DUAL, SO8, NJM5532M-TE2 256429
U2 OP AMP, DUAL, SO8, NJM5532M-TE2 256429
U3 CMOS ANALOG MUX, DUAL 4-CHANNEL,
DG409CY
256483
U4 MICRO RESET CIRCUIT, SOT23,
MAX809JEUR
250096
U5 MICRO, PROGRAMMED, PIC16F877 256469-001
U6 SERIAL EEPROM, 128X8 BIT, SOIC8, 24C01A 184044
U7 OP AMP, DUAL, SO8, NJM5532M-TE2 256429
U8 OP AMP, DUAL, SO8, NJM5532M-TE2 256429
U9 CMOS ANALOG MUX, DUAL 4-CHANNEL,
DG409CY
256483
U10 +5V, RS232 TRANSCVR, SO16, MAX202CSE 256487
U11 SENSOR, IR DET, RPM-7138-H5, NO SHLD 256780-001
U12 VOLT REG, 5V, TO 252 (DPAK), L78M05 197227-001
U14 +8V REG, TO 92, 78L08 146234
U15 OP AMP, DUAL, SO8, NJM5532M-TE2 256429
U16 2 INPUT POS AND GATE,5 PIN SOP 261421
Reference
Designator
Description Part Number Note
T1 XFMR, S/PDIF 254185
T2 XFMR, S/PDIF 254185
T3 XFMR, S/PDIF 254185
T4 XFMR, S/PDIF 254185
T5 XFMR, STANDBY, DUAL PRIMARY,
115/230V, 50/60Hz
256458 3
F1 POLYSWITCH, FUSE, RESETTABLE, 50V,
100mA HOLD CURRENT
190348-010 3
F2 POLYSWITCH, FUSE, RESETTABLE, 50V,
100mA HOLD CURRENT
190348-010 3
F4 FUSE, T4A, 5x20mm, 250V, 4A, SLO BLO 177311-04000 3
FC1 CLIP, FUSE, PCB MOUNT 178548 3
FC2 CLIP, FUSE, PCB MOUNT 178548 3
J4 RIBBON CABLE, J4 IO TO J9 DSP, 14 COND 256462
J5 CONN, HOUSING, AC, 125V, 7A 146563 3
J6 HDR, PCB MNT, 5 POS, L&R A IN, L&R V IN,
IR I/O
177291-05
J7 RJ-45 JACK 196357
J8 HDR, PCB MNT, 4 POS, LIFESTYLE INPUT,
FRONT OUT, REAR OUT
177291-04
