Miscellaneous (continued)
I/O PCB ELECTRICAL PART LIST
Reference
Designator
Description Part Number Note
J9 HDR, PCB MNT, 3 POS, SERIAL I/O,
TV&EXT PWR
177291-03
J10 HDR, PCB MNT, 5 POS, L&R A IN, L&R V IN,
IR I/O
177291-05
J11 HDR, PCB MNT, 3 POS, SERIAL I/O,
TV&EXT PWR
177291-03
J12 HDR, PCB MNT, 4 POS, LIFESTYLE INPUT,
FRONT OUT, REAR OUT
177291-04
J13 HDR, PCB MNT, 2 POS, CENTER & BASS
OUTPUT
177291-02
J14 HDR, PCB MNT, 4 POS, LIFESTYLE INPUT,
FRONT OUT, REAR OUT
177291-04
J15 HDR, PCB MNT, 2 POS, CENTER & BASS
OUTPUT
177291-02
J18 HDR, PCB MNT, 3 POS, XFMR PRIMARY 261417-03 3
J21 HDR, PCB MNT, 5 POS, L&R A IN, L&R V IN,
IR I/O
177291-05
J22 CONN, HEADER, SOCKET, PCB MNT 133224-15
JP1 JUMPER, 6MM 261418
JP3 JUMPER, 6MM 261418
S1 SWITCH, DIP, SM, PCB MNT, 2 CKT 256774-002
S4 SWITCH, DIP, SM, PCB MNT, 4 CKT 256774-004
S7 SWITCH, DIP, SM, PCB MNT, 4 CKT 256774-004
S9 SWITCH, POWER, PCB MNT, SPST, 125V, 16A 196101 3
K1 RELAY, DPDT, 5V 256476-05
Y1 RES, CER, 8.00MHZ +/- .5% 180997
U5a SOCKET, SM, POL, 44PIN PLCC W/POST 256488
