Bose L1 II User Manual

25
Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C120 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C121 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C122 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C123 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C124 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C125 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C126 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C127 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C128 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C129 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C130 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C134 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C135 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C136 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C137 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C138 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C139 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C140 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C141 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C142 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C143 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C146 10uF, CE, 25V, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106MJJC 4
C147 10uF, CE, 25V, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106MJJC 4
C150 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C151 47pF, 0603, CC, 50V, 5%, 1x2 150F-470JAC 4
C152 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C153 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C154 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C155 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C156 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C157 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C158 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C159 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C160 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C161 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C162 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C163 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C164 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C165 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C166 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C167 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C168 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C169 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C170 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
