Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C171 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C173 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C174 470pF, 0603, CC, 50V, 5% 150F-471JAC 4
C175 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C176 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C177 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C180 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C181 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C182 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C183 220pF, 0603, CC, 50V, 5% 150F-221JAC 4
C184 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C185 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C191 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C192 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C195 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C196 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C200 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C201 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C202 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C203 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C204 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C205 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C206 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C207 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C208 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C209 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C210 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C211 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C212 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C213 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C214 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C215 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C216 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C217 10uF, CT, 16V, 20%, SMD, 1.6X3.2 154D-106MCF 4
C218 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C219 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C220 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C221 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C222 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C223 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C224 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C225 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C228 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C229 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C230 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C231 1uF, 0603, CC, 10V, 20% 150C-105ZAC 4
