Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C232 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C233 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C234 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C235 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C236 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C237 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C238 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C239 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C240 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C241 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C242 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C243 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C244 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C245 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C246 10uF, CT, 16V, 20%, SMD, 1.6X3.2 154D-106MCF 4
C247 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C248 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C249 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C252 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C253 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C254 470pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-471JAC 4
C255 470pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-471JAC 4
C256 470pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-471JAC 4
C257 470pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-471JAC 4
C258 0.015uF, 0603, CC, 50V, 10% 150F-153KAC 4
C259 0.015uF, 0603, CC, 50V, 10% 150F-153KAC 4
C260 47uF, CT, 85C, 16V, 10%, SMD, 6.0X3.2 154D-476KKF 4
C261 1uF, CT, 16V, 20%, SMD, 1.6X3.2 154D-105MCF 4
C262 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C263 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C264 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C265 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C266 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C267 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C268 1uF, 0805, CC, 10V, 10% 150C-105KBD 4
C272 22pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-220JAC 4
C273 22pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-220JAC 4
C274 2200pF, 0603, CC, 50V, 10%, 0.8x1.6 150F-222KAC 4
C275 2200pF, 0603, CC, 50V, 10%, 0.8x1.6 150F-222KAC 4
C276 6800pF, 0603/1608, CC, 50V, 10%, 1X2 150F-682KAC 4
C277 6800pF, 0603/1608, CC, 50V, 10%, 1X2 150F-682KAC 4
C278 22uF, CE, 16V, 20%, SMD, 5X5.8,
UUD1C220MCR1GS, NICHICON
157D-226MIKC 4
C279 22uF, CE, 16V, 20%, SMD, 5X5.8,
UUD1C220MCR1GS, NICHICON
157D-226MIKC 4
