33
Electrical Part List
Input/Output PCB Assembly
Integrated Circuits (continued)
Reference
Designator
Description Vendor Part
Number
Note
U116 VOLT REG, L7815ACD2T, D2PAK, ST 3132-3881 4
U117 STEP-DOWN CONVERTER, MP1591DN, SOIC8N,
MPS
3132-4711 4
U118 REG, NCP1117ST33T3G, 3.3V, SOT-223 3132-1481 4
U119 RESET, MCP100T-315I/TT, SOT23, MICROCHIP 3132-4481 4
U120 STEP-DOWN CONVERTER, MP1591DN, SOIC8N,
MPS
3132-4711 4
Miscellaneous
Reference
Designator
Description
endor Part
Number
Note
CN101 2P, ST. WAFER, P=2.0, COULOMB 2102-020S 4
CN102 2P, ST. WAFER, P=2.0, COULOMB 2102-020S 4
CN301B-B WAFER, 2P, P7.92, STRAIGHT 2101-3092 4
E1B SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
E2B SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
F100 THERMAL FUSE, 40A, MAX 60V, MAX PTC,
RESETTABLE, 8X5.5
5201-5006 3, 4
F101 THERMAL FUSE, 40A, MAX 60V, MAX PTC,
RESETTABLE, 8X5.5
5201-5006 3, 4
FOR DSP COVER, SHIELD, BSPAPS2 4135-6841 4
FOR J102 BRACKET, POWER STAND, 4P, SPK SOCKET 4135-3801 4
J100 JACK, PHONE, 5P, 6.4MM, BLACK, W/SW
(BOSE
®
PART NUMBER 741427-001S)
2113-3269 4
J101 JACK, PHONE, 5P, 6.4MM, BLACK 2113-3270 4
J102 SPEAKON
®
NEUTRIK
®
, 4 WIRE, NL4MD-V 2113-1336 4
J103 JACK, RJ45, ST-NE8FAV, 8 PIN, NEUTRIK 2113-3210 4
J301B 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J301L 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J302B 6 PIN WF 2102-060S 4
J302L 6 PIN WF 2102-060S 4
J303B 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J303L 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
L100 FERRITE CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878 4
T100 CHOKE, CM, 2200 OHM, AT, 100 MHZ, SM,
DLW31SN222SQ2L, MURATA
1806-3966 4
T101 CHOKE, CM, 2200 OHM, AT, 100 MHZ, SM,
DLW31SN222SQ2L, MURATA
1806-3966 4
T103 PULSE TRANSFORMER, 225uH, 0.35 OHM, 1=1,
100K
1806-3670 4
T104 PULSE TRANSFORMER, 225uH, 0.35 OHM, 1=1,
100K
1806-3670 4
VR1 VR-ROTARY, 100KAX2, 20%, V, L15, D, LOW
RESIDUAL ALPHA
4751-1359 4
X100 CRYSTAL, HC49, 12.288MHZ, 20PPM, 4.7X13 2300-3284 4
To Next Page
