Electrical Part List
Resistors
Power Amplifier PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R1 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R3 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R5 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R6 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R7 16K, 0805, RMG, 1/10W, 1% 4720-163A 4
R8 12K, 1206, RMG, 1/4W, 1% 4725-123A 4
R9 9.1K, 0805, RMG, 1/10W, 1% 4720-912A 4
R10 9.1K, 0805, RMG, 1/10W, 1% 4720-912A 4
R13 1M, 0603/1608, RMG, 1/16W, 5% 4723-105J 4
R14 1M, 0603/1608, RMG, 1/16W, 5% 4723-105J 4
R16 0 OHM, 0805, RMG, 1/10W, 5% 4720-000J 4
R18 6.8K, 0603/1608, RMG, 1/16W, 1% 4723-682A 4
R19 9.1K, 0805, RMG, 1/10W, 1% 4720-912A 4
R20 4.7 OHM, RWR, 5W, 5%, RL 474B-4R7J 3, 4
R21 64.9K, 0603, RMG, 1/16W, 1% 4723-6492 4
R22 0 OHM, 0805, RMG, 1/10W, 5% 4720-000J 4
R23 9.1K, 0805, RMG, 1/10W, 1% 4720-912A 4
R26 64.9K, 0603, RMG, 1/16W, 1% 4723-6492 4
R27 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R28 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R29 12K, 1206, RMG, 1/4W, 1% 4725-123A 4
R30 16K, 0805, RMG, 1/10W, 1% 4720-163A 4
R34 10 OHM, 1206, RMG, 1/4W, 5% 4725-100J 4
R35 10 OHM, 1206, RMG, 1/4W, 5% 4725-100J 4
R38 10 OHM, 0805, RMG, 1/10W, 1% 4720-100A 4
R39 10 OHM, 0805, RMG, 1/10W, 1% 4720-100A 4
R41 4.7 OHM, RWR, 5W, 5%, RL 474B-4R7J 3, 4
R45 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R46 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R47 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R48 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R53 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R54 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R55 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R56 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R58 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R61 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R62 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R63 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R64 1K, 0603/1608, RMG, 1/16W, 1% 4723-102A 4
R66 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R67 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
