Electrical Part List
Resistors (continued)
Power Amplifier PCB Assembly
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
R231 10 OHM, 0805, RMG, 1/10W, 1% 4720-100A 4
R232 36K, 0603, RMG, 1/16W, 1% 4723-363A 4
R233 36K, 0603, RMG, 1/16W, 1% 4723-363A 4
R238 36K, 0603, RMG, 1/16W, 1% 4723-363A 4
R239 36K, 0603, RMG, 1/16W, 1% 4723-363A 4
R241 36K, 0603, RMG, 1/16W, 1% 4723-363A 4
R291 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R300 10K, 1206, RMG, 1/8W, 5% 4721-103J 4
Reference
Designator
Description Vendor Part
Number
Note
C1 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C2 0.47uF, 0805/2012, CC, 16V, 10%, 1.5X2.5 150D-474KBDL 4
C3 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C4 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C5 2700pF, 0805, CC, 50V, 10%, 1.2X2.0 150F-272KBD 4
C6 47pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-470JAC 4
C7 330pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-331JAC 4
C8 0.22uF, 0805, CC, 16V, 10%, 1.2X2.0 150D-224KBD 4
C9 220pF, 1206, CTC, 0/30, 100V, 5% 15CG-221JCFH 4
C10 3300pF, 0805, CC, 50V, 10%, 1.2x2.0 150F-332KBD 4
C11 680pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-681JBD 4
C12 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C13 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C14 4.7uF, 1206, CC, Y5V, 16V, 20% 150D-475ZCF 4
C15 0.47uF, CM, 100V, 10%, RB, 7.5X8 153H-474KNO 4
C16 0.33uF, CM, 100V, 5%, RBT, 7.5X9.5, MKS2, WIMA 153H-334JNRU 4
C17 3300pF, 0805, CC, 50V, 10%, 1.2x2.0 150F-332KBD 4
C18 2700pF, 0805, CC, 50V, 10%, 1.2X2.0 150F-272KBD 4
C19 680pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-681JBD 4
C20 0.22uF, 0805, CC, 16V, 10%, 1.2X2.0 150D-224KBD 4
C21 4.7uF, 1206, CC, Y5V, 16V, 20% 150D-475ZCF 4
C22 0.47uF, CM, 100V, 10%, RB, 7.5X8 153H-474KNO 4
C23 220pF, 1206, CTC, 0/30, 100V, 5% 15CG-221JCFH 4
C24 0.33uF, CM, 100V, 5%, RBT, 7.5X9.5, MKS2, WIMA 153H-334JNRU 4
C25 2200pF, 0603, CC, 50V, 10%, 0.8x1.6 150F-222KAC 4
C26 2200pF, 0603, CC, 50V, 10%, 0.8x1.6 150F-222KAC 4
C27 47pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-470JAC 4
C28 330pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-331JAC 4
C29 0.47uF, 0805/2012, CC, 16V, 10%, 1.5X2.5 150D-474KBDL 4
C31 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C32 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C33 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C34 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C35 0.01uF, 0805, CC, 50V, 20%, 1.2x2.0 150F-103MBD 4
