Bose L1 II User Manual

37
Electrical Part List
Capacitors (continued)
Power Amplifier PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
C36 0.01uF, 0805, CC, 50V, 20%, 1.2x2.0 150F-103MBD 4
C37 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C38 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C39 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C40 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C43 2200uF, CE, 50V, 105C, 20%, RL, 18X31 157F-228M7$T 4
C44 2200uF, CE, 50V, 105C, 20%, RL, 18X31 157F-228M7$T 4
C45 220pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-221JAC 4
C46 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C47 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C48 2.2uF, CM, 50V, 5%, RLT, 10X8, METALLIZED 153F-225JSOM 4
C49 2.2uF, CM, 50V, 5%, RLT, 10X8, METALLIZED 153F-225JSOM 4
C51 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C52 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C53 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C54 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C56 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C57 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C58 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C59 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C60 220pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-221JAC 4
C61 220pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-221JAC 4
C62 220pF, 0603, CTC, 0/60, 5%, 0.8X1.6 15CH-221JAC 4
C63 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C68 0.1uF, 0603/1608, CC, 50V, 10%, 1x2 150F-104KAC 4
C100 0.33uF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K03Z 4
C103 0.015uF, 1206, CC, 630V, 10%, X7R 150M-153KCF 4
C104 0.015uF, 1206, CC, 630V, 10%, X7R 150M-153KCF 4
C105 0.015uF, 1206, CC, 630V, 10%, X7R 150M-153KCF 4
C106 0.015uF, 1206, CC, 630V, 10%, X7R 150M-153KCF 4
C107 680uF, CE, 105C, 200V, 20%, RL, 25X35 157U-687M&^T 4
C108 680uF, CE, 105C, 200V, 20%, RL, 25X35 157U-687M&^T 4
C109 1000pF, CC, 400V, 20%, RL, 9X6 150T-102MQK 4
C110 1000pF, CC, 400V, 20%, RL, 9X6 150T-102MQK 4
C111 2200pF, CC, 400V, 20%, RL, 10X6 150T-222MSK 4
C112 0.33uF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K03Z 4
C200 680pF, 0603, CTC, 0/60, 5% 15CH-681JAC 4
C201 0.22uF, 0805, CC, 16V, 10%, 1.2X2.0 150D-224KBD 4
C202 0.47uF, CM, 400VDC, 5%, RB, P15, 18X17.5X9 1511-474J0T 4
C203 0.47uF, CM, 400VDC, 5%, RB, P15, 18X17.5X9 1511-474J0T 4
C204 1uF, 0805, CC, 25V, 10% 150E-105KBD 4
C205 1uF, 0805, CC, 25V, 10% 150E-105KBD 4
C206 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C207 2.2uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-225KCFM 4
C208 1uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-105KCFM 4
C210 470pF, 2211, CC, 250VAC, 10%, 2.8X5.7 150R-471KEKZ 4
