38
Electrical Part List
Capacitors (continued)
Power Amplifier PCB Assembly
Inductors
Diodes
Reference
Designator
Description Vendor Part
Number
Note
C211 1uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-105KCFM 4
C212 470pF, 2211, CC, 250VAC, 10%, 2.8X5.7 150R-471KEKZ 4
C213 470pF, 2211, CC, 250VAC, 10%, 2.8X5.7 150R-471KEKZ 4
C214 100pF, 0603/1608, CC, 50V, 5%, 1X2 150F-101JAC 4
C215 100pF, 0603/1608, CC, 50V, 5%, 1X2 150F-101JAC 4
C216 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C217 1000pF, 0805, CTC, 0/30, 5%, 1.2x2.5 15CG-102JBD 4
C218 470pF, 2211, CC, 250VAC, 10%, 2.8X5.7 150R-471KEKZ 4
C219 1uF, 1206, CC, 50V, 10%, X7R, MURATA 150F-105KCFM 4
C220 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C221 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C222 470uF, CE, 35V, 105C, 20%, RL, 10X20 157Q-477MS9T 4
C223 470uF, CE, 35V, 105C, 20%, RL, 10X20 157Q-477MS9T 4
C226 0.15uF, 0805, CC, 50V, 10% 150F-154KBD 4
C227 0.15uF, 0805, CC, 50V, 10% 150F-154KBD 4
C300 0.01uF, CC, 50V, 10%, 1206, 1.6x3.2 150F-103KCF 4
Reference
Designator
Description Vendor Part
Number
Note
L1 CHOKE, COIL, 10uH, 10%, 7A, T94-2 1806-3899 4
L3 CHOKE, COIL, 10uH, 10%, 7A, T94-2 1806-3899 4
L6 FERRITE BEAD INDUCTOR, BL01RN1A1F1J 1808-0680 4
L7 FERRITE BEAD INDUCTOR, BL01RN1A1F1J 1808-0680 4
L8 CHOKE, COMMON MODE, 2X16uH, 8A, FT50-43 1806-3913 4
L100 CHOKE, COMMON MODE, 2X10MH, 3A, TC-2510 1806-3934 4
L101 CHOKE, COMMON MODE, 2X10MH, 3A, TC-2510 1806-3934 4
L200 INDUCTOR, 10uH, 1210, 500MA, SMD 1803-0092 4
L201 INDUCTOR, 10uH, 1210, 500MA, SMD 1803-0092 4
Reference
Designator
Description Vendor Part
Number
Note
Z200 ZENER, 0.4W, 15V, BZX284-B15 4840-9230 4
Z201 ZENER, 1/2W, 11V, SOD110, SMD, BZX284-C11@115 4837-1109 4
D1 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D2 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D3 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D4 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D5 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D6 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D7 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D8 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D9 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D10 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
D14 200V, 250MA, 50NS, BAS321, SOD323 480S-3210 4
