Bose L1 II User Manual

39
Electrical Part List
Diodes (continued)
Power Amplifier PCB Assembly
Transistors
Reference
Designator
Description Vendor Part
Number
Note
D100 BRIDGE, 800V, 8A, GBU8K, RL 4840-9218 4
D200 600V, 1A, 75NS, US1J, SOD124 480U-S1J0 4
D201 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D202 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D203 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D204 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D205 RECTIFIER, 100V, 12A, 12CWQ10FNTRBF, DPAK,
SMDIR
4840-9213 4
D206 RECTIFIER, 100V, 12A, 12CWQ10FNTRBF, DPAK,
SMDIR
4840-9213 4
D207 RECTIFIER, 100V, 12A, 12CWQ10FNTRBF, DPAK,
SMDIR
4840-9213 4
D208 RECTIFIER, 100V, 12A, 12CWQ10FNTRBF, DPAK,
SMDIR
4840-9213 4
D209 RECTIFIER, 200V, 1A, RS1D, SOD124 4840-9212 4
D210 RECTIFIER, 200V, 1A, RS1D, SOD124 4840-9212 4
D211 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D212 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D216 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D217 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D218 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
D290 75V, 250MA, 4NS, BAS216, SOD110 480S-2160 4
Reference
Designator
Description Vendor / Bose
®
Part Number
Note
Q1 MOSFET, N-CH, FDD368, 2_NL, 100V, 32A, TO-252AA 291330 4
Q2 MOSFET, N-CH, FDD368, 2_NL, 100V, 32A, TO-252AA 291330 4
Q3 MOSFET, N-CH, FDD368, 2_NL, 100V, 32A, TO-252AA 291330 4
Q4 MOSFET, N-CH, FDD368, 2_NL, 100V, 32A, TO-252AA 291330 4
Q5 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q6 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q200 MOSFET, N-CHANNEL, STB12NM50FDT4, D2PAK 291329 4
Q201 MOSFET, N-CHANNEL, STB12NM50FDT4, D2PAK 291329 4
Q202 REGULATOR, 5V, LM78L05ACM, SO-8 3131-3390 4
Q203 NPN, BCP56-10, SOT223 485C-P560 4
Q204 REGULATOR, 250MA, LM79L05, SO8 3132-3091 4
Q205 NPN/PNP PAIR, FFB2227A, SC70-6 4852-27A0 4
Q206 NPN/PNP PAIR, FFB2227A, SC70-6 4852-27A0 4
Q207 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q208 MOSFET, N-CH, 60V, 115MA, 2N7002, SOT-23 4907-0020 4
Q209 MOSFET, N-CH, 60V, 115MA, 2N7002, SOT-23 4907-0020 4
Q210 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q211 BC846B, SOT23, PHILIPS, SMD 4858-46B0 4
Q290 PUMZ1, NPN/PNP PAIR, SOT363 485U-MZ10 4
