Bose Panaray 502C Service Manual

13
502A Array (see Figure 4)
MAIN PART LIST
Product code 040170 (gray) and 040171 (white) are a RoHS compliant version of the 502A.
Only RoHS compliant parts listed in the above chart can be used in the 502A with product code
040170 and 040171.
Item
Number
Description Part Number Qty. Note
1 Grille, Pro Gray
Grille, Arctic White
142342-01
142342-02
1
2 Insert, Threaded, Mach, M8x10.5, Gray
Insert, Threaded, Mach, M8x10.5, Wht
143552-01
143552-02
2
3 Nameplate, Dark Gray/Arctic White
Nameplate, Dark Arctic White/Dark Gray
130718-1B21
130718-1C31
1
4 Nut, Push-On,.078 125786 2
5 Driver, 4.5” 291025-001 5
6 Screw, HIRS, 8-10x5/8, PAN, XRC/SQ 289388-010 20
7 Gasket, Driver, 4.5" 128407 5
8 1234356789898989 119094-3R0 1
9 Capacitor, 5µF, Mylar 102770 1
10 Tape, Foam 118223 2
11 Terminal, Connector, Wire wrap 118008 4
12 Inductor, .75mH, Air core 293515-001 1
13 Washer, Flat Aluminum 123840 1
14 Gasket, Connector Panel 290316-001 1
15 Screw, 8-10, OVL HD, 1/2", BK (Gray)
Screw-8-10, OVL HD, 1/2", Zn (White)
Screw, Tapp, 8-10x .5, OVL CSK, BLK
148378-08
148379-08
290978-08
4 Non-RoHS
Non-RoHS
RoHS
16 Connector Panel, XLR, Gray
Connector Panel, XLR, White
Connector Panel, Barrier, Gray
Connector Panel, Barrier, White
Connector Panel, Speakon
®
, Gray
Connector Panel, Speakon, White
142344-01
142344-02
142344-03
142344-04
287072-003
287072-002
1 Non-RoHS
Non-RoHS
Non-RoHS
Non-RoHS
RoHS
RoHS
17 Fuse holder, Knob with O-Ring 149268 1
18 Fuse-Standard Delay, 4A 104715-400 1
19 Fuse holder Body 149269 1
20 Washer, Neoprene 149270 1
21 Screw, Tapp, 4-16x1/2, PAN (XLR)
Screw, HIRS, 8-10x3/4, PAN (Barrier)
Screw, M2.6x5/8, Phillips, Flat (Speakon)
145724-08
137527-12
-
4
2
4
Non-RoHS
Non-RoHS
RoHS
22 Connector, XLR, Dual
Connector, Barrier Strip, 4 pos.
Connector, Speakon, Panel Mount
145717
148976-04
258213
1
1
2
Non-RoHS
Non-RoHS
Non-RoHS
23 Gasket, XLR Connector
Gasket, Barrier
Gasket, Speakon (inc. with item 22)
146874
171243
-
1
1
2
Non-RoHS
Non-RoHS
RoHS
24 Batting, Polyester 142360 2
25 Foam, Acoustic 142361 1
26 Fuse holder Nut 171731 1
