502A CSB-5A Suspension Bracket Kit Parts List (see Figure 20)
ACCESSORY KIT PART LIST
Item
Number
Description Part Number Qty.
Note
1 Suspension Bracket 148519 2 1
- Hardware Kit, Consists of: 173536 1
2 Screw, Mach., Socket Cap, M8x12mm 148514 7
2 Lock washer, M8 173450 7
3 Quick Link, 1/8" 148520-1 5
4 Allen Wrench, 6mmx3" 148544-2 1
- Poly bag, Hardware 173362 1 7
- Instruction Sheet 148521 1 1, 7
- Poly sleeve, Bracket 173361 2 1, 7
- Carton 173363 1 1, 7
- Carton Divider 173364 1 1, 7
Figure 20. CSB-5A Suspension Bracket Kit
