Bose Panaray 502C - 502 B CSB-5 B Suspension Bracket Kit Parts List (See Figure 21)

48
Figure 21. CSB-5B Suspension Bracket Kit
502B CSB-5B Suspension Bracket Kit Parts List (see Figure 21)
ACCESSORY KIT PART LIST
1
2
3
Item
Number
Description Part Number Qty. Note
1 Left Angle Bracket 147005-1 1 1
1 Right Angle Bracket 147005-2 1 1
- Hardware Kit, Consists of: 173537 1
2 Screw, Hex Head, Mach., M8x20mm 148545-10 5
2 Lock washer, M8 173450 5
3 Quick Link, 3/16" 148520-2 2
- Poly bag, Hardware 173376 1 7
- Instruction Sheet 148527 1 1, 7
- Poly sleeve, Bracket 173375 2 1, 7
- Tube, Packing 173377 1 1, 7
- Carton, Divider 173378 1 1, 7
