Bose Panaray 502C Service Manual

18
502C Controller (removable front panel version) (see Figure 7)
MAIN PART LIST
Item
Number
Description Part Number Qty. Note
1 Cover, Chassis, 502C 173003 1
2 Screw, Tapp, 4-40x.375, PAN, TORX
(US/Can.)
Screw, Tapp, 4-40x.375, PAN, TORX
(Euro/UK/Aus/Japan)
170284-06
170284-06
2
8
9
9,10
3 Plate, Front, Rack Mount Kit 173004 1
4 Screw, Tapp, 4-40x.312, BTN, XREC 170285-05 4 11
5 Lens, LED, Clear, Front Panel 144023 1
6 Switch, Rocker, SPST, AC Power 143960 1 5
7 PCB Assembly, 502C (US/Can)
PCB Assembly, 502C
(Euro/UK/Aus/Japan)
143940-1
143940-2
1
1
1, 6
1, 6
8 Screw, Mach, 4-40x.25, PAN, TORX
(US/Can)
171796-04 5 12
Screw, Mach, 4-40x.25, PAN, TORX
(Euro/UK/Aus/Japan)
171796-04 2
9 Transformer, 120V (US/Can.)
Transformer, 220-240V (Euro/UK/Aus)
Transformer, 100V (Japan)
143950-1
143950-2
143950-3
1 5
10 Nut, Hex, STND, Washer, KEPS 118260-08 2
11 Insulator, Standoff, PCB 143948 1 1, 5
12 Connector, Barrier Strip Assy,
6 position (US/Can.)
143971 3
13 Screw, Tapp, 4-40x.5, PAN, TORX
(US/Can.)
170284-08 6
14 Nut, Hex, #8-32, Steel (US/Can/UK/Aus.) 103237-832 1
15 Line Cord, 3 wire (US/Can.)
Line Cord, 2 wire (Euro)
Line Cord, 2 wire (Japan)
Line Cord, 3 wire (UK)
Line Cord, 3 wire (Aus)
143975
143977
143976
149023
149024
1 5, 13
16 Heatsink, PCB Mount 147165 1 1
- Screw, Tapp, 4-40x.375, PAN, XREC 170284-06 4 7, 8
- Chassis, 502, US/Canada
Euro/UK/AUS/Japan
173002-01
173002-02
1
1
1
