Bose Panaray 502C Service Manual

46
502A PSA-5 Stand Adapter Parts List (see Figure 19)
ACCESSORY KIT PART LIST
Figure 19. PSA-5 Stand Adapter Kit
Item
Number
Description Part Number Qty. Note
1 Mounting Bracket 148513 2 1
- Hardware Kit, Consists of: 173535 1
2 Thumbscrew, M8x25mm, Black 173355 4
2 Washer, Thumbscrew 173356 4
3 Bolt, Button Head, 5mm, M8x12mm, Black 148526-02 8
4 Bolt, Button Head, 5mm, M8x20mm, Black 148526-10 2
5 Lock washer, M8 173450 10
6 Allen Wrench, 5mm 148544-1 1
- Poly bag, Hardware 173358 1 7
- Instruction Sheet 148515 1 1, 7
- Poly sleeve 173357 2 1, 7
- Carton, RSC 173359 1 1, 7
- Carton, Divider 173360 1 1, 7
1
2
3
4
5
6
